GBJ High Efficiency Agitating Tank

1. Bigger Diameter of the impeller, strong agitating capacity for the slurry and medicament.

2. Bigger linear velocity of impeller strong agitating capacity for the slurry and medicament.

3. Umbrella-shaped impeller strengthens the agitation and circulation of the slurry and medicament.

4. The stronger the agitating ability the stronger the circulating ability of slurry and medicament.

5. A guide flow device is equipped in the tank. Strong negative pressure is compressed in the limited room which increases the suction ability and the circulating ability of slurry and medicament.


Model

Effective volume (m³)

Impeller revolution (r.p.m)

D.of impeller(mm)

Motor model

Motor power(kw)

Weight(kg)

GBJ-1000×1000

0.58

530

240

Y112M-6

2.2

548

GBJ-1250×1250

1.15

350

240

Y100L2-4

3

1108

GBJ-1500×1500

2.2

320

420

Y132M2-6

5.5

2207

GBJ-2000×2000

4.4

240

560

Y160M-6

7.5

3110

GBJ-2500×2500

9.2

272

560

Y180L-6

15

3939

GBJ-3000×3000

19.1

211

700

Y225S-8

18.5

4613

GBJ-4000×4000

45

153

1000

Y250M-8

30

9560
