NG Peripheral Drive Thickener

【Introduction】: Peripheral transmission thickener has two kinds, peripheral roller transmission and peripheral gear transmission.

【 Capacity 】: 87~3000t/d.

【Improvement】: Single row cross column rotary support or single row four-point contact ball rotary support, collector device with good insulation, exposed rotary parts with light shield.

NG thickener is a kind of running roller type peripheral drive thickener. Large-scale thickener usually adopts such type of peripheral traction. The running roller skidded once overload, no special safety device is required. Its tank is usually made of concrete. In order to charge the motor, annular nodes are arranged on the central support.

The current collection joints with the sliding ring are connected with the arm brace and the current is introduced to the motor through these joints by the cable laid on the arm brace.


Unique bridge design, excellent rigid strength and strong overload capacity.

Peripheral roller transmission, low energy consumption, stable and reliable operation.

Simple operation, convenient maintenance and remote control.

This thickener consists of round thickener and harrow scrapping machine, the solid particles suspend in thickener settling by gravity, the pulp in the upper turn into clean water so that the separation can be realized. The slime that sediment in the bottom of the thickener is discharged by the harrow scrapping continuously, and clean overflow from the upside.

Model

Thickening tank diameter (mm)

Thickening tank Depth (mm)

Capacity(t/h)

Sediment area (㎡)

Motor model

Motor power(kw)

Weight(kg)

NG-15

15000

3500

390

177

Y132M2-6

5.5

9120

NG-18

18000

3500

560

255

Y132M2-6

5.5

10564

NG-24

24000

3400

1000

452

Y160M-6

7.5

24000

NG-30

30000

3940

1560

707

Y160M-6

7.5

26420

NG-45

45000

5060

2400

1590

Y160L-6

11

50640
