FX Hydro Cyclone

Hydraulic cyclone is a kind of equipment for classifying the ore pulp by centrifugal force. It has no motion and dynamic parts, but it requires matching with a corresponding slurry pump. It is mainly used in ore dressing industry for classifying, sorting, thickening and desliming.

Hydraulic cyclone has the features like low equipment cost, easy assembling and dismantling, convenient maintenance, small floor space required, low capital expenditure, large processing capacity of unit volume, fine classifying grain size, high classifying efficiency, small quantity and short time of staying of the ore pulp in the cyclone, and easy operation of shutdown.

Used for classifying the ore pulp in the grinding loop. A combined unit is usually selected by connecting several units of cyclone in parallel. It’s classifying fineness and processing capacity are greatly affected by the diameter of upper cylinder pressure at the inlet of ore pulp and the concentration of ore pulp. therefore, it has a large fluctuation of process.


Specifi-cations

Internal diameter

(mm)

Inlet diameter

(mm)

Overflow pipe diameter

(mm)

Underflow diameter

(mm)

Cone-angle

(°)

Max-

imum feeding particle size

(mm)

Feed pressure

(pa)

Capacity

(m³/h)

Separated particle size

(µm)

Dimension

Wei-ght(kg)

L

(mm)

W

(mm)

H

(mm)

FX-660

660

187,167

180,200,

220,240

80,110,150

20

16

0.03-0.4

250-360

74-220

1215

850

2720

950

FX-500

500

130

120

130,140,

160,180,

220

35,45,50,65,

70,80,90,100

25

10

0.03-0.4

140-220

74-200

951

718

1825

416

20

74-200

850

623

1825

490

10

74-150

951

718

2280

556

FX-350

350

80

80,90,

105,115,

120

30,35,40,45,

50,60,70

25

6

0.03-0.4

60-105

50-150

530

413

1411

135

20

50-150

530

413

1411

155

15

50-120

530

413

1674

230

FX-300

300

64

75

65,80,

100,120

20,25,30,

35,40

20

5

0.03-0.4

45-90

50-150

530

410

1305

88

15

40-100

563

410

1490

169

FX-250

250

55

74

80

60,75,80,

100,120

16,18,20,25,

30,35,40

20

3

0.05-0.4

40-65

40-100

563

534

1178

63

15

40-100

548

390

1057

120

10

30-100

548

415

1380

123

FX-200

200

48

40,50,

55,65

16,20,24,

28,32

20

2

0.05-0.4

25-40

40-100

548

307

1025

36

15

30-100

320

307

1114

64

FX-150

150

36

30,35,

40,45

8,10,12,14,

16,18,20,22

20

1.5

0.05-0.4

11-20

30-74

320

270

682

22

15

30-74

252

349

899

20

8

20-74

290

295

1267

60

FX-125

125

26

25,30,

35,40

8,10,12,

14,16,18

17

1

0.05-0.4

8-15

20-100

280

185

617

10

8

20-74

210

240

973

12

FX-100

100

23

20,25,

30,40

8,10,12,

14,16,18

20

1

0.05-0.4

5-12

20-100

250

210

525

8

15

10-100

257

210

575

5

8

10-74

257

210

829

6

FX-75

75

13

15,17,20

6,7,8,10,12

15

0.6

0.1-0.5

2-5

20-74

240

230

459

4

7

5-40

240

230

700

7

FX-50

50

9

11,13,

15,18

3,6,8,10,12

15

0.3

0.1-0.5

1.5-3

10-74

160

152

325

2

6

5-30

160

152

550

2.5

FX-25

25

5

5,6,7,8

2,3,4,5

5

0.2

0.1-0.5

0.3-1

3-10

160

152

587

0.8

3

2-10

120

110

576

1.4

FX-10

10

2

2,3,4

1,2

4

0.1

0.1-0.1

0.05-1

1-5

60

34

140

0.5
